ControlArt – 7Port Mini

Driver for integrating the ControlArt 7Port Mini IR/RF/RTS gateway with Control4. It provides native access to the IR outputs, so any device with a Control4 driver can be controlled by infrared.

With the companion drivers in the package, it controls relays and RF 433 devices (gates, fireplaces, motors) and shades and blinds with IR, RF 433 and RTS motors. This driver is exclusive to the 7Port Mini hardware.

Installation

1. Set the 7Port Mini IP with 7Config.
2. Add the driver to the project and enter the IP in the “IP Address” property (and the “TCP Port”, if needed).
3. Enter the key in “License Key” (the driver has a 30-day trial).
4. Use the “Importar IDs RTS do 7Port” (import RTS IDs) Action to read the RTS IDs after additions or removals made in 7Config.

Features

• Native access to the IR outputs for any device with a Control4 driver
• 3 IR ports and 1 relay on the 7Port Mini
• Control of RF 433 devices and RTS motors
• Extra drivers for IR/RF relays, IR/RF commands and IR, RF 433 and RTS shades
• Import of the RTS IDs registered in 7Config
• Adjustable delays between IR and RF/RTS commands
• Automatic reconnection to the gateway

Requirements

• ControlArt 7Port Mini gateway with a static IP
• IP configured with 7Config
• Control4 OS 2.9.1 or later, with internet access for the license

Release notes

1. 4059/9/2023

   Licensing system update.

2. 40311/11/2021

   Fixed the RTS motor index initialization.

3. 4026/6/2021

   Licensing system update.

4. 4015/5/2021

   OS 2.9.1 compatibility.

5. 4003/2/2021

   Initial version.
